OOPOWER fogging machine

O O POWER MACHINERY CO.LTD is Professional manufacturer of asphalt machines. Our sales and R&D team have over 10 years’ experience to focus on asphalt distributor, synchronous pavement surface vehicles and other road machinery and equipment. Based on innovation

About OOPOWER fogging machine

Fuel Tank Capacity	2L	Max. Efficiency	11 minute per Tank Medicine(13L)
Medicine Tank Capacity	13L	G.W./N.W	13.0/8.2KGS
Fuel Consumption	3.2 litres/hours	The size	1230315370Mm

Individual fogging machine details

1. Professional production line and experienced engineers to control the quality;

2. Easy to assemble and operate；

3. FG40 Fogging Machine can be used for COVID2019 disinfection by means of atomizing the aqua sterilisata. Prevention and control throughly no dead Angle!

4. It can be used to repel and kill insects with the insecticide in backyard, gardens and other areas;

5. High work efficiency and long-lasting with increased temperature

fuel tank capacity:2L

Medicine Tank Capacity:13L

Fuel Consumption:3.2 litres/hours

Max. Efficiency :11 minute per Tank Medicine(13L)

G.W./N.W.:13.0/8.2KGS

The size :1230*315*370Mm

OO POWER fogging machine detail Pictures

The fogging machine contains accessories

1.Suspenders

2.Spark plug

3.Left-to-right accessory name

4.Chargers

5.Size funnel

6.Instruction Manual

7.Tool Kit

8.Gas Mask

9.Canteens

Packaging display

Dimensions:

1230*315*370Mm

Purpose

1.A drop of liquid entrained in a gas

Points to note

1.Safe use of machines, must be anti-virus, fire, anti machine accident. Must pay attention to the thought, raise vigilance. Must not be careless, to ensure personal safety.

Should be aware of the following

1． machine is strictly forbidden in flammable and explosive place.

2． Smoke machine series is made of gasoline as fuel, for flammable, should pay attention to fire. Smoking and smoking is forbidden in the gasoline engine.

3． No ignition igniter check open carburetor.

4． After refueling should fuel tank cap screw. If there is fuel leakage should be cleaned. Move the machine away from the point of service and start up.

5． The machine should be stored before the carburetor in the fuel tank drain. Clean the machine. Stored in ventilation, away from the fire source. Long time should be placed every 30 days to the battery charge 5 hours.

1． Prohibited in the machine working state or just shutdown or add out of fuel.

2． When operating the machine, the high temperature parts do not touch people or animals. As shown in Figure 2, avoid accidental injury. Water forced cooling after the shutdown, this will seriously damage the machine.

3． When working in the field, the working personnel should be operated in the air outlet, and can not follow the direction of the wind. In the indoor operation, staff should be from the inside to the outside of the operating machine, when the door to the door, and shut down the door, to ensure that the body is safe and effective to kill insects and viruses.

1． It is forbidden to use electric arc or acetylene on a machine that has pesticide and gasoline to change or cut. When the fuel tank or the pesticide tank is leaking, please contact the dealer or the professional personage.

2.The safety instructions provided by the pesticide manufacturer should be followed in the process of dealing with the residual pesticides or cleaning the pesticide containers.

3． The use of machine application is completed, should be promptly closed the valve, then turn off the engine. If the engine stops, the valve must be shut down quickly.

1.When the machine is working, no one is allowed to enter the work area.

2． Storage should not allow children to access, so as to avoid accidents.

3． The operator must wear PPE in accordance with the following requirements. (Figure5)

a. Must wear work clothes: work clothes must fit, can not prevent action. Can't wear a skirt, wear a coat can't wear scarf tie and jewelry.

b . Must take the gloves

c . Must wear protective shoes

d . Must wear a helmet

e . Must wear a gas mask

f . Must wear ear plugs (especially long hours).

Main technical specifications and standards

Name	Mist sprayer	Mist sprayer
specifications and models	FS63	FS70
Residual liquid（L）	﹤0.1	﹤0.1
Power Supply	12v Rechargeable battery	12v Rechargeable battery
Rated spray volume（L／h）	100	120
Gasoline consumption（L／h）	2.5～3	3～3.5
Nozzle inner diameter（MM）	28～30	30～32
fuel tank capacity（L）	2.0	2.0
Fuel	Petrol 92	Petrol 92
work environment	-10℃～25℃	-10℃～25℃
net weight（KG）	9.0	9.5
size（LWH MM）	1100340	1300340
